SERIES S3000 T-SEAM METAL ROOF PANEL

B&B Sheet Metal S3000 T-Seam Panel is a nominal 3” deep structural roofing system, which is constructed to provide excellent structural spanning capabilities. The T-Seamed panel insures a high, weather-tight seam even in the lowest, longest roof runs found in today’s building designs.

S3000 profile

S3000 INTERLOCK SEAM

TRIM

All flashings and trim are available to be manufacturer by B&B Sheet Metal to match with panel selection. B&B Sheet Metal’s capabilities include press-breaking, notching, shearing, welding and much more. Shop drawings of flashing details are available upon request. B&B Sheet Metal can provide assistance to typical flashing standards and conditions. For more information of details of flashings and trim contactus directly.

INSTALLATION

Series S3000 T-Seam Panel system may be specified for application over solid deck, 5/8” plywood with 2 layers of 15# felt or 1 layer of 30# felt or 22 gauge metal deck with 2 layers of 15# felt or 1 layer of 30# felt, minimum pitch ½:12” (specify as required). The Series S3000 TSeampanel may be specified for applications over solid deck or open framing. Fixed S3000 panel clip are installed and fastened, butting the next panel forming a “T” and placing the cap over the panels then run the mechanical seamer to seal the panels; optional sealant before capping the two panels may be applied. Contact B&B Sheet Metal for details on mechanical seamers.
Finish & Color Availability

MATERIALS

  • .032 and .040 Kynar Aluminum
  • 24ga and 22ga Kynar Steel
  • Galvalume Plus
  • 16oz and 20oz Copper
  • .032 and .040 Mill Finish Aluminum
  • 26ga, 24ga and 22ga Galvanized
Finish & Color Availability

PRODUCT ATTRIBUTES

  • Structural
  • Architectural detail capability
  • Tight radius curving capacity
  • Shallow slope (less than 3:12)
  • Narrow seam
  • Wide seam
  • Flush seam
  • Snap-lock seam
  • Mechanical seam
  • Good transition for mansard or fascia
  • UL-90 Tested
  • Florida Building Code Compliant
  • ASTM water & air infiltration tested
  • Dade County Tested
  • ASTM E-84 Tested
  • ASTM E-1592 Tested
  • Weathertightness warranties
  • FM Tested

Related Project

We Have More Related Projects To Upload

BB Sheet metal- Tunxis Community College- Phase II Campus

Tunxis Community Colloge

, ,

PHASE II CAMPUS DEVELOPMENT TUNXIS COMMUNITY COLLEGE Project Description Project Name: PHASE II CAMPUS DEVELOPMENT TUNXIS COMMUNITY COLLEGELocation: Farmington, CTDate Completed: To Be Announced Project Component Type: SERIES S3000 T-SEAM [...]
