SERIES A1101 1” INTEGRAL SNAP-LOCK ROOF PANEL

B&B Sheet Metal’s Series A1101 defines clean lines with architectural interchangeability to provide continuous seam transitions from roof to fascia, wall panel or soffit. The A1101 narrow standing seam profile requires no mechanical seaming or separate seam cap. The integrated nail strip and fasteners provides a clipless design for fast and easy installation ideal for light duty commercial metal roofs, residential and mansard/canopy applications on a solid deck. Maximum panel length is 45 feet and minimum 24 inches.
A1101 profile

A1101 INTERLOCK SEAM

TRIM

All flashings and trim are available to be manufacturer by B&B Sheet Metal to match with panel selection. B&B Sheet Metal’s capabilities include press-breaking, notching, shearing, welding and much more. Shop drawings of flashing details are available upon request. B&B Sheet Metal can provide assistance to typical flashing standards and conditions. For more information of details of flashings and trim contact us directly.

INSTALLATION

Series A1101 panel system may be specified for application over solid deck, 5/8” plywood with 2 layers of 15# felt or 1 layer of 30# felt or 22 gauge metal deck with 2 layers of 15# felt or 1 layer of 30# felt, minimum pitch 3:12 (specify as required). Apply fasteners at the nail strip of the panel for a seamless and clipless design.
Finish & Color Availability

MATERIALS

  • .032 and .040 Kynar Aluminum
  • 24ga and 22ga Kynar Steel
  • Galvalume Plus
  • 16oz and 20oz Copper
  • .032 and .040 Mill Finish Aluminum
  • 26ga, 24ga and 22ga Galvanized
Finish & Color Availability

PRODUCT ATTRIBUTES

  • Structural
  • Architectural detail capability
  • Tight radius curving capacity
  • Shallow slope (less than 3:12)
  • Narrow seam
  • Wide seam
  • Flush seam
  • Snap-lock seam
  • Mechanical seam
  • Good transition for mansard or fascia
  • UL-90 Tested
  • Florida Building Code Compliant
  • ASTM water & air infiltration tested
  • Dade County Tested
  • ASTM E-84 Tested
  • ASTM E-1592 Tested
  • Weathertightness warranties
  • FM Tested
